Vertical 3-in-1 Carton Erector Case Packing & Sealing Machine

The vertical 3-in-1 case packer is a high-efficiency packaging solution that combines automatic case forming, vertical product loading, bottom sealing and top sealing into a single compact unit, significantly optimizing workshop floor space for industries such as food, medicine and daily chemicals. Equipped with an advanced PLC control system and an intuitive touchscreen interface, the machine provides precise monitoring of the entire packaging process and supports rapid changeovers for various carton sizes, while its stable vertical loading mechanism minimizes product damage and ensures consistent packaging quality, making it an ideal choice for enhancing production line automation and overall throughput.

Model: WKD-KZF-V10
Power: 3Phase, 380V, 50/60HZ, 10KW
Air Consumption: 800-1000L/min
Feeding Height: 1100mm
Packing Speed: ≤4-8 cases/min
Carton Size: L200-500*W190-380*H190-350mm
Packing Mode: Gripper picking &placing
Sealing Type: Tape/Hot melt glue
Overall Dimensions: L3800*W1300*H1650mm
Machine Weight: Approx. 2.5t

Quantity:
Availability:





Inquire Add to Basket

3 In 1 Case Sealer case packing Case Packer Machine automatic packer

Product Description

3-in-1 Ultra-Integrated Architecture: Combines case erecting, vertical loading, and sealing in one unit, significantly reducing the floor space required and eliminating synchronization issues between separate machines.
2.5-Ton Heavy-Duty Reinforced Frame: The 2.5-ton solid steel construction provides extreme mechanical rigidity, effectively absorbing vibrations to guarantee zero-damage to delicate aerosol cans even during high-speed operation.
Siemens & inovance Core Control: Powered by a Siemens PLc and HMl combined with Inovance servo drivers for milisecond-level synchronization of picking, lifting and sealing cycles.
Vertical Gripping for Nozzle Protection: Features a servo-driven mechanical gripper system combined with HiWiN linear guides for precise neck-clamping, ensuring cans are placed vertically without damaging the valve or spray head.
Versatile sealing Options: Supports both adhesive tape and hot melt glue sealing, offering the flexibility to meet various industrial standards and aesthetic requirements.
SICK Smart Monitoring System: Integrated with German SICK sensors to monitor carton forming, can placement, and sealing status in real-time, guaranteeing zero-missing and error-free cycles.
